Citadel Bed Frame System
To extend the bed frame:
1. Level the deck before adjusting the bed length.
2. Rotate the blue extension locking handle (1) located under the foot end of
bed and pull out the bed frame (2) to the required position and release the
handle. Ensure extension locks in position.
)LJXUH([WHQGLQJWKHEHGIUDPH
To extend the deck:
1. Lift the blue extension locking handles on either side of the bed (1). Pull
out the deck extension (2) to the required position and release the handles.
Ensure deck extension locks in position.
)LJXUH([WHQGLQJWKHGHFN
After extending the deck make sure the calf extension sheet is clipped
RYHUWKHHQGRIWKHGHFNIUDPH
2. To shorten the bed: Reverse the above procedures.
