Citadel Bed Frame System
Controls for Television and Lighting (Optional Feature)
Button controls for television and lighting are located on the head end side rails. The
side rails also contain loudspeakers for television sound.
)LJXUH79DQGOLJKWLQJFRQWUROVSDWLHQW¶VOHIWKDQGVLGH
1. Closed Captioning on / off
2. Television on / off
3. Decrease volume
4. Increase volume
5. Sound on / off (mute)
6. Main room lights on / off
7. Reading lamp on / off
8. Channel down
9. Channel up
The bed must be connected to a compatible Headwall system for the TV and lighting
controls to operate. The bed’s electronics will recognize the type of television in use
DQGFRQ¿JXUHWKHFRQWUROVDXWRPDWLFDOO\
The controls have been designed to be compatible with the majority of TV sets found in
hospitals. If you encounter any problems, please contact the Arjo Service Department.
1
2 3
4
5 67
89
