Citadel Bed Frame System
*XLGDQFHDQGPDQXIDFWXUHU¶VGHFODUDWLRQ±HOHFWURPDJQHWLFLPPXQLW\
Immunity test ,(&
test level
Compliance level Electromagnetic
environment - guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±2kV, ±4kV, ±8kV,
±15kV air
±8kV contact
±2kV, ±4kV, ±8kV,
±15kV air
±8kV contact
Floors should be wood,
concrete or ceramic tile.
,IÀRRUVDUHFRYHUHGZLWK
synthetic material the relative
humidity level should be at
least 30%
Conducted
disturbances
inducted by RF
¿HOGV
EN 61000-4-6
3V in 0,15 MHz to
80 MHz
6V in ISM and
amateur radio
bands between
0,15 MHz and 80
MHz
80% AM at 1 kHz
3V in 0,15 MHz to 80
MHz
6V in ISM and amateur
radio bands between
0,15 MHz and 80 MHz
80% AM at 1 kHz
Portable and mobile RF
communications equipment
should be used no closer
to any part of the product,
including cables, than 1.0m,
if the transmitter’s output
power rating exceeds 1W
a
.
)LHOGVWUHQJWKVIURP¿[HG5)
transmitters, as determined
by an electromagnetic site
survey,
should be less than the
compliance level in each
frequency range
b
.
Interference may occur in the
vicinity of equipment marked
with this symbol:
Radiated RF
electromagnetic
¿HOG
EN 61000-4-3
Professional
Healthcare
environment
3 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
Professional
Healthcare
environment
3 V/m
80 MHz to 2,7 GHz
80% AM at 1 kHz
3UR[LPLW\¿HOGV
from RF wireless
communications
equipment
EN 61000-4-3
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz
- 9V/m
810, 870, 930 MHz
- 28 V/m
1720, 1845, 1970,
2450 MHz - 28 V/m
5240,5500, 5785
MHz - 9V/m
385 MHz - 27 V/m
450 MHz - 28 V/m
710, 745, 780 MHz -
9V/m
810, 870, 930 MHz - 28
V/m
1720, 1845, 1970,
2450 MHz - 28 V/m
5240,5500, 5785 MHz
- 9V/m
Electrical fast
transient/burst
EN 61000-4-4
±1kV SIP/SOP
ports
±2kV AC port
100kHz repetition
frequency
±1kV SIP/SOP ports
±2kV AC port
100kHz repetition
frequency
Mains power supply should be
that of a typical comercial or
hospital environment.
Power frequency
0DJQHWLF¿HOG
EN 61000-4-8 30A/m
50 Hz or 60 Hz
30A/m
50 Hz
Power frequency magnetic
¿HOGVVKRXOGEHDWOHYHOV
characteristic of a typical
location in a typical
commercial or hospital
environment.
