27
description parameter sensorless open loop closed loop
Language 001 English English English
Local/remote control 002 Local Remote Remote
Local reference 003 0.000 0.000 0.000
Active setup 004 Multi setup Setup 1 Setup 1
Programming setup 005 Active setup Active setup Active setup
Copying of setups 006 No copy No copy No copy
lcp copy 007 No copy No copy No copy
Display scaling of motor frequency 008 1.00 1.00 1.00
Display line 2 009 Frequency [hz] Frequency [hz] Frequency [hz]
Display line 1.1 010 Sensorless head [kpa] Reference [%] Reference [Unit]
Display line 1.2 011 Sensorless power [W] Motor current [Amps] Feedback [Amps]
Display line 1.3 012 Sensorless flow [L/s] Power [kW] Power [kW]
Local control/configuration 013 lcp dig control/par 100 lcp dig control/Par 100 lcp dig control/par 100
Local stop 014 Enable Enable Enable
Local jog 015 Enable Disable Disable
Local reversing 016 Disable Disable Disable
Local reset of trip 017 Enable Enable Enable
Lock for data change 018 Not locked Not locked Not locked
Operating state at power up,
Local control
019 Auto restart Local = Stop Local = Stop
Configuration 100 Speed open loop Speed open loop Process closed loop
Torque characteristics 101 Constant torque Variable torque – med Variable torque – med
Motor power 102 Unit dependant Unit dependant Unit dependant
Motor voltage 103 Unit dependant Unit dependant Unit dependant
Motor frequency 104 Unit dependant Unit dependant Unit dependant
Motor current 105 Unit dependant Unit dependant Unit dependant
Rated motor speed 106 Unit dependant Unit dependant Unit dependant
Resonance damp 117 O O O
dc braking time 126 10.0 seconds 10.0 seconds 10.0 seconds
dc brake cut -in frequency 127 O O O
Motor thermal protection 128 Disable Disable Disable
dc braking voltage 132 O O O
Start voltage 133 Motor dependant Motor dependant Motor dependant
Start compensation 134 100.0% 100.0% 100.0%
u/f ratio 135 Motor dependant Motor dependant Motor dependant
Slip compensation 136 0.00% 100.0% 100.0%
dc holding voltage 137 O 0% 0%
Brake cut -out frequency 138 3.0hz 3.0hz 3.0hz
Brake cut -in frequency 139 3.0hz 3.0hz 3.0hz
Rotation direction 200 132hz ctr-clockwise 132hz ctr-clockwise 132hz ctr-clockwise
Minimum frequency 201 21hz 0hz 0hz
Maximum frequency 202 50hz (60 some models) 50hz (60 some models) 50hz (60 some models)
Reference/feedback range 203 Min- max Min- max Min- max
Minimum reference 204 0hz 0hz (Sensor min)
Maximum reference 205 50hz (60 some models) 50hz (60 some models) (Sensor max)
Ramp up time 1 207 10.00 seconds 10.00 seconds 10.00 seconds
Ramp down time 1 208 3.0 seconds 3.0 seconds 3.0 seconds
Ramp up time 2 209 3.0 seconds 3.0 seconds 3.0 seconds
Ramp down time 2 210 3.0 seconds 3.0 seconds 3.0 seconds
Jog ramp time 211 10.00 seconds 10.00 seconds 10.00 seconds
Quick stop ramp down time 212 3.0 seconds 3.0 seconds 3.0 seconds
Jog frequency 213 50hz 50hz 50hz
Reference function 214 Sum Sum Sum
Preset reference 1
(copy of parameter 241)
215 000.00% 000.00% As required [%]
Preset reference 2 216 000.00% 000.00% 000.00%
Catch up/slow down value 219 000.00% 000.00% 000.00%
Current limit for motor mode 221 100% 100% 100%
Frequency bypass bandwidth 229 O O O
Frequency bypass 1 230 0.00 hz 0.00 hz 0.00 hz
Frequency bypass 2 231 0.00 hz 0.00 hz 0.00 hz
Preset reference 1
(copy of parameter 215)
241 000.00% 000.00% As required [%]
Preset reference 2 - 7 242 - 247 000.00% 000.00% 000.00%
