Associated Research OMNIA II 8207 User Manual

235
Resolution
0.1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
Range 3
0.0uA ~ 31.5uA, DC
Resolution
0.1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
Range 4
0.0uA ~ 126.0uA, DC
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
Range 5
0.0uA ~ 504uA, DC
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
Range 6
0.0uA ~ 999.9uA, 1000uA ~ 1200uA,
DC
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
DISPLAY AUTO RANGE
Touch Current Display (Peak)
(AC+DC)
Range 1
0.0uA ~ 32.0uA, frequency DC, 15Hz
– 1MHz
Resolution
0.1uA
Accuracy
DC: ±(2% of reading + 2uA)
,15Hz < f <1MHz: ±(10% of reading +
2uA)
Range 2
28.0uA ~ 130.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC: ±(2% of reading + 2uA)
,15Hz < f <1MHz: ±(10% of reading +
2uA)
Range 3
120.0uA ~ 525.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC: ±(2% of reading + 2uA)
,15Hz < f <1MHz: ±(10% of reading +
2uA)
Range 4
400uA ~ 999.9uA, 1000uA-2100uA,
