2
Single-action operation for selecting input channels, partial display/non-display of
information, picture overlay and freeze/update using the switches on the front
panel
Many different display modes available
Picture, waveform, vector, audio level meter, audio vector mode, multi display and picture waveform
simultaneous display modes
Compare mode provided
Frozen images and the current images can be displayed for the purposes of comparison.
Lighting of red, green LEDs at top of screen using external control (contact supply
type)
Loading of preset data enabled by external control (contact supply type)
Preset switches provided on front panel (for loading and saving the preset data)
Automatic tracking of input signals supported
Automatic 1/1.000 and 1/1.001 frame rate tracking and input signal detection
functions
Reference input (HD analog tri-level sync, BB_525, BB_625)
CRC error detection function (during HD-SDI input) for input channels
Time code (VITC) display (during HD-SDI input)
Functions for locking the panel switches and storing the settings
Light weight and slim-line dimensions
DC 12V supported (10-18V)
Camera battery supported
