Chapter 3 OPERATION
63
3.4.11.4 Compare mode 3
〈〈 Functions 〉〉
In this mode, the waveforms of the images for the freeze data and current input data are displayed
simultaneously side by side at the left and right. The settings are as shown below.
Setting item What happens on multi mode 2 screen
Scale color As set
Cursor As set
Line select Invalid
[ WAVEFORM mode ]
Setting item What happens on multi mode 2 screen
Parade display/overlay display Value selected by switch
Y/G ON or OFF Value selected by switch
Pb (Cb) / B ON or OFF Value selected by switch
Pr (Cr) / R ON or OFF Value selected by switch
SWEEP Fixed at 1H
GAIN Fixed at 100%
MAG
×1
Vertical (gain) scroll Fixed at initial value
Horizontal scroll Fixed at initial value
Waveform YPbPr/GBR/RGB Value selected by switch
V Anc (Wave) ON or OFF As set
H Blank ON or OFF As set
Scale %/V As set
Filter As set
Waveform color, brightness As set
MONO As set
MARKER As set
[ Description of operations ]
Switch Description of function
FUNC switch No function.
F1 switch
Parade / Overlay
Use this to switch between parade display (side-by-side display) and overlay display
(superimposed display).
F2 switch
Y
Use this to set Y/G to ON or OFF.
F3 switch
Pb (Cb)
Use this to set Pb/B to ON or OFF.
F4 switch
Pr (Cr)
Use this to set Pr/R to ON or OFF.
F5 switch
Waveform YPbPr /
Waveform GBR /
Waveform RGB
Use this to switch the waveform display between YPbPr, GBR and RGB.
