Chapter 4 MAIN SPECIFICATIONS
77
4.9 General specifications
Table 4.1 Operating environment and ratings for WM-3014 (main unit)
Operating temperature range 0 to 40 °C
Operating humidity range
30 to 80%RH (ambient temperature must be in the 0 to 40 °C range
and no condensation must be allowed to form)
Rated voltage DC10-18V
Power consumption 20W (typ)
Service life 35,000 hours (with LCD backlight brightness reduced to one-half)
Dimensions
210 (W) × 133 (H) × 83 (D) mm (excluding protrusions)
210 (W) × 133 (H) × 105 (D) mm (including protrusions)
Weight Approx. 1.5 kg
Table 4.2 Operating environment and ratings for accessory AC/DC adapter
Rated output voltage
12V ± 5%
Rated output current 5.0A
Maximum output power 60W
Input voltage Rating: 100-240V (AC)
Pin 1 GND
Pin 2 NC
Pin 3 NC
Output plug polarities
Pin 4 POWER
