Chapter 4 MAIN SPECIFICATIONS
75
Setting item Setting/adjustment range Initial value
SWEEP 1H, 2H, 1F, 2F 1H
GAIN (WAVEFORM mode)
×0.03 to ×7.97 ×1
CTR Pos. C Aligned, Center Aligned
H cursor ON, OFF OFF
V cursor ON, OFF OFF
MOVE BASE, OFFSET, TRACK BASE
Waveform YPbPr. GBR YPbPr
V Anc (Wave) ON, OFF OFF
H Blank ON, OFF OFF
Scale (unit) %, V, Non %
Filter (Wave) NON, LPF, Average LPF
GAIN (VECTOR mode)
×0.03 to ×7.97 Fix ×1
V Anc (Vect) ON, OFF OFF
Scale (display) 100%, 75% 100%
Filter (Vect) NON, LPF, Average LPF
Cardinal numbers HEX, DEC, OCT, BIN HEX
GAIN (AUDIO mode)
Fix ×1, ×2, ×4, ×8, ×16 Fix ×1
Animation ON, OFF ON
Power Save Mode 1, 5, 10, 15, 30, 60, NON NON
* These settings are not stored in the memory. They are always OFF when the power is turned on.
Setting items by channel
The following items are set separately for each SDI A, SDI B, analog channel and composite channel.
Setting item Setting/adjustment range Initial value
Bright -50.0 to +50.0% 0.00%
Contrast 0.0 to 200.0% 100.0%
Pb (Cb) 0.0 to 200.0% 100.0%
Pr (Cr) 0.0 to 200.0% 100.0%
Chroma_UP ON, OFF OFF
Y Gamma 1.100 to 4.400 2.200
Peaking OFF, 1 to 100 OFF
Filter ON, OFF ON
Mono ON, OFF OFF
Green ON, OFF ON
To Next Page
