66
4.2 Input signal systems
SDI input
specification
Specification
HDTV
BTA S-004B complied with,SMPTE 292M complied with, NRZI SDI
signal
SDTV SMPTE 259M complied with, NRZI SDI signal
SDI input
Field (frame) frequency, 60.00/59.94 [Hz], etc. automatically tracked
Automatic tracking of input format enabled
Analog input
specification
Specification
BTA S-001B complied with,SMPTE 274M complied with, SMPTE 296M
complied with,
Field frequency, 60.00/59.94 [Hz], etc. automatically tracked
Automatic scanning of input format enabled
HDTV YPbPr input
Y on Sync or reference signal selected for synchronization
Video signals: 75Ω ±5% termination
Reference signal: 75Ω ±5% termination
(Signal measurement accuracy: Within ±5%, horizontal jitter: less than 10ns)
Composite input
specification
Specification
NTSC SMPTE170M complied with
PAL ITU.R BT624-4 complied with in part
* PAL-M and PAL-N are not supported.
COMPOSITE input
Automatic scanning of input format enabled
(Signal measurement accuracy: Within ±5%)
4.3 Display system
Display system Specification
Liquid crystal a-Si TFT LCD
Colors displayed 16,194,277 colors
Contrast ratio 300:1 (Max)
Angle of view 105 degrees vertically, 120 degrees horizontally
Brightness 250 cd/m
2
(max)
Screen size 6.3 inch
Resolution
1024 (H) × 768 (V) Pixels
Image area HDTV
960 (H) × 540 (V) Pixels
Pixel pitch
0.126 (W) × 0.126 (H) mm
When composite signals are input, the 3 lines each at the start and end of the video
signals will appear to be disturbed compared with the actual waveforms, and displayed.
CAUTION
