Chapter 3 OPERATION
27
[ Description of operations ]
Switch Description of function
FUNC switch No function.
F1 switch
Mono
Use this to set monochrome to ON or OFF.
When monochrome is set to ON, Green, Blue and Red are set to ON.
F2 switch
Green
Use this to display or not display the green of the input images. If Green is set to OFF
while monochrome is ON, monochrome will be set to OFF.
F3 switch
Blue
Use this to display or not display the blue of the input images. If Blue is set to OFF while
monochrome is ON, monochrome will be set to OFF.
F4 switch
Red
Use this to display or not display the red of the input images. If Red is set to OFF while
monochrome is ON, monochrome will be set to OFF.
F5 switch
Marker
Use this to set the markers to ON or OFF. At the marker ON setting, select the markers
using the adjustment dial, and enter the selection by pressing the adjustment dial.
Note: With the 525i/60 and 625i/50 formats, the 4:3, 13:9 and 14:9 markers are not
displayed. Furthermore, if there are no input signals and
AUTO has been selected for the format, the 1080 marker is displayed.
