ASUS RS540-E9-RS36-E
1-5
* Specifications are subject to change without notice.
Model Name
RS540-E9-RS36-E
Graphic
VGA
Aspeed AST2500 with 64MB VRAM
Front I/O Ports
2 x USB 2.0 ports
Rear I/O Ports
2 x USB 3.1 Gen 1 ports
1 x VGA port
2 x RJ-45 GbE LAN ports
1 x RJ-45 Mgmt LAN port
Switch/LED
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Reset switch
1 x HDD Access LED
1 x Message LED
LAN 1-4 LED
* LAN3-4 for Mezzanine card use
Rear Switch/LED:
1 x Power switch
1 x Q-Code/Port 80 LED
1 x Message LED
1 x HDD LED
1 x Location LED
Security Options
Trusted Platform Module (TPM 2.0) Header
OS Support
Please nd the latest OS support from http://www.asus.com
Regulatory Compliance
BSMI, CE, CB, FCC
Management
Solution
Software
ASUS Control Center (Classic)
Out of Band
Remote
Management
ASMB9-iKVM for KVM-over-Internet
Dimension (HH x WW x DD)
615mm x 447mm x 176mm (4U)
Net Weight Kg
(CPU, DRAM & HDD not included)
27.73 Kg
Power Supply
1+1 Redundant 800W 80 PLUS Platinum Power Supply
1+1 Redundant 1600W 80 PLUS Platinum Power Supply
Power Rating
For 800W:
100-127Vac/200-240Vac, 10A/5A, 50/60Hz, Class I
(for each inlet)
For 1600W:
100-127Vac/200-240Vac, 50-60Hz, 13A/9.5A or 240Vdc
(China only), 9.3A, Class I (for each inlet)
Environment
Operating temperature: 10°C – 35°C
Non operation temperature: -40°C – 70°C
Non operation humidity: 20% – 90% (Non condensing)
