Asus RS540-E9-RS36-E - Internal Features

ASUS RS540-E9-RS36-E
1-9
1.6 Internal features
The barebone server includes the basic components as shown.
1. Redundant power supply
2. 2.5-inch Storage Device Bay
3. ASUS Z11PR-D16 Server Board
4. SATA/SAS Backplane Board
5. Asset Tag (hidden)
6. System fans
7. Hot-swap 3.5-inch Storage
Device Bay
The barebone server does not include a oppy disk drive. Connect a USB oppy disk drive
to any of the USB ports on the front or rear panel if you need to use a oppy disk.
*WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
Turn off the system power and detach the power supply before removing or replacing any
system component.
