Asus RS540-E9-RS36-E - Page 81

ASUS RS540-E9-RS36-E
4-23
19. M.2 (NGFF) card connectors (NGFF1-2)
These connectors allow you to install M.2 devices.
This connector supports type 2242 / 2260 / 2280 devices on both PCI-E and SATA
interface.
The M.2 (NGFF) device is purchased separately
18. VROC KEY connector (4-pin VROC_KEY1)
This connector allows you to connect a KEY module to enable additional CPU RAID
functions with Intel
®
CPU RSTe.
The KEY module is purchased separately.
