Chapter 2 –
User interfaces
UM-23100B-U User
manual
ATEQ F CLASS
Page 20/90
7. FUNCTIONS OF THE INDICATOR LIGHTS
The
symbol represents an indicator which is lit.
Test part OK indicator
T
R
Reference side BAD part
indicator
T
R
Test side BAD part indicator
T
R
Warning
T
R
Sleep
(intermittently flashing indicator)
T
R
Recoverable parts
(indicators continuously lit)
T
R
29
31
