ATEQ F SERIES User Manual

Chapter 3 – Start-up and settings
UM-23100B-U User manual ATEQ F CLASS Page 22/90
2.1. CHOICE OF THE PROGRAM NUMBER
Position the cursor in front of the
chosen program number and confirm
with the ENTER key.
PARAMETERS
Copy-Paste
Pr :001 ----------
Pr :002 ----------
2.2. TEST TYPE SELECTION
Four types of test are available.
The PARAMETERS menu gives
access to four possible types of test :
leak test (LEAK TEST), pressure test
(BLOCAGE), desensitised mode test
(D. MODE) and an operator test
(OPERATOR); see the following
paragraph for explanations.
Put the cursor in front of the required
test type and confirm with the ENTER
key.
PARAM/TYPE
LEAK TEST
BLOCKAGE
D MODE
2.2.1. Leak test
The leak test is most suitable for measuring small
leaks (pressure drop). The following formula is used
to convert a leak expressed in units of flow to a drop
in pressure:
)(cm V x 0,0006
/min)(cm F
(Pa/s) P
3
3
=∆
F(cm
3
/min) = Leak flow
0.0006 = constant
V (cm
3
) = volume of the test part
∆P (Pa/s) = pressure drop
Example :
Part which has dP/dt = 50 Pa/s Part which has dP/dt = 1 Pa/s
Test
1 s
2 s
3 s
.
.
n s
Pa/s
50
50
50
.
.
50
Pa
50
100
150
.
.
nx50
Test
1 s
2 s
3 s
.
.
n s
Pa/s
1
1
1
.
.
1
Pa
1
2
3
.
.
n
The choice of working in Pa or in Pa/s depends on the application.
In all events, it must not be forgotten that the full scale of the sensor in Pa or Pa/s is
limited to 50 or 500 Pa depending on the instrument configuration.
