ATEQ F SERIES User Manual

Chapter 4 – Functions of the instrument
UM-23100B-U User manual ATEQ F CLASS Page 71/90
Note: if the parameters have been modified, then current and saved parameters are
therefore different, when the instrument begins to operate, the following message is
displayed on the screen.
This message is not jamming and disappears after a
few seconds. It allows informing that a parameters
saving can be necessary. In this case three solutions
arises:
SAVE PARAMETERS
1) Restore the saved (current parameters will be lost).
2) Save the current parameters in the memory (the parameters already in the memory
will be lost).
3) Nothing to do and working with the current parameters.
4.2. SENSORS SERVICE
This menu is used to monitor the information communicated by the pressure sensors,
"PRESSURE" for the absolute pressure piezo sensor and "LEAK" for the differential
leak sensor.
In the main menu, position the cursor
beside MAINTENANCE and confirm
by pressing ENTER.
MAIN
MENU
SPE CYCLE: Disabled
CONFIGURATION
SERVICE
Then position the cursor beside
SENSORS and confirm by pressing
ENTER.
M
AI
N
/
SERVIC
E
PARAMETERS
SENSOR
The values measured by the pressure
sensors are then displayed on the
screen.
M
AI
N
/
SERVI
/
SENSOR
PRESSURE : 0000
LEAK : 0000
