UM-23100B-U User manual ATEQ F CLASS Page 86/90
2. MECHANICAL DEFINITION DRAWINGS OF F CLASS
C
www.ateq.com
250
180
136
21
22 99
SOL
4 x M6
10mm threaded profile
270
