ATEQ F SERIES User Manual

Chapter 4 – Functions of the instrument
UM-23100B-U User manual ATEQ F CLASS Page 41/90
2. CONFIGURATION MENU
2.1. EXTENDED MENUS
The extended menus offer access to additional functions If these functions are
activated, they can be found in the FUNCTION menu when a program is created (refer
to 3 paragraph 2.3.13). If no additional functions are activated, the FUNCTION menu
will be empty when a program is created. .
2.1.1. Activation of the additional functions
In the main menu, place the cursor in
front of the CONFIGURATION label
MAIN
MENU
SPE CYCLE :Disabled
CONFIGURATION
RESULTS
Confirm using the ENTER key.
CONFIGURATION
EXTENDED MENUS
PRINTER : YES
HOUR
Next, confirm the EXPANDED
MENUS function with the ENTER
key. The list of additional functions is
then displayed.
CONFI/EXTEND
MENUS
NAME : No
CYCLING : No
AUTO CONNECT : No
To activate a function (e.g. the NAME
function), confirm it with the ENTER
key. Next, choose YES with the
navigation keys and confirm again
with the ENTER key. Start the
operation again if you need to
activate other functions.
CONFI/EXTEND
MENUS
NAME :Yes
CYCLING :No
AUTO CONNECT :No
Once all the chosen functions are
activated, press the CANCEL key
twice to return to the main menu.
C C
MAIN MENU
SPE CYCLE :Disabled
CONFIGURATION
RESULTS
