ATEQ F SERIES User Manual

Chapter 4 – Functions of the instrument
UM-23100B-U User manual ATEQ F CLASS Page 42/90
2.1.2. Setting the additional functions
9 Place the key in the ACCESS position .
9 Create a new program (refer to chapter 3 paragraph 2 "Creation of a test program").
9 In the parameters list for this new program, confirm the FUNCTIONS parameter
(refer to chapter 3 paragraph 2.3 "Parameter settings").
Only the functions which have been activated using the above method will
appear in the FUNCTIONS parameter.
2.1.3. List of additional functions
2.1.3. 1) Name
This function is used to customise a program, for example to name a program after the
part to be tested.
)Select the option and enter settings if necessary.
2.1.3. 2) Program sequencing
This function enables several tests to be carried out by the instrument one after the
other. The instrument offers 8 program sequencing criteria.
The sequencing order can be edited; the choice of the following program is defined in the
parameters. By default the programs are sequenced according to their original number P+1.
When an active program is sequenced with another
program, a "+" is displayed behind the program
number.
MAIN
MENU
RUN PROG. : 01+
PARAMETERS
SPE CYCLE :none
Associated parameters to be set: NEXT PROGRAM, INTER-CYCLE (wait or coupling
time between two cycles). Chaining conditions: ALL RESULTS (under all result
conditions), PASS (part good), TEST FAIL (test part bad), REFERENCE FAIL
(reference part bad), ALARM, PRESSURE OUT (pressure error), REWORKABLE (parts
which can be repaired), CALIBRATION (calibration error).
)Select the option and enter settings if necessary.
2.1.3. 3) Automatic connector
The automatic connector is a pneumatic control enabling the driving of an external logic
(pneumatic sealing connector). This control is activated at the start of the cycle and is
released at the end of the cycle (refer to “cycle end” diagram paragraph 2.1.3.10)
If several programs are chained, the automatic connectors are activated according to
the times set as parameters in the first program and are deactivated according to the
times set as parameters in the last program in the chain.
They remain active throughout all cycles between the first and last program in the chain.
The various waiting times A are applied in the programs in between.
Associated parameters to be set: WAIT A, WAIT B.
)Select the option and enter settings if necessary.
