ATEQ F SERIES User Manual

Chapter 4 – Functions of the instrument
UM-23100B-U User manual ATEQ F CLASS Page 35/90
Chapter 4
FUNCTIONS OF THE INSTRUMENT
1. MENU STRUCTURE
MAIN MENU Under menu 1 Under menu 2 Under menu 3 Under menu 4
CYCLE PROG.
> 1 to 16
v
PARAMETERS
> Copy Paste > Copy
v
v Paste
v
v
v
Programs
01 to 16
> Leak > Type: leak > Reset name
v
v Wait A Delete program
v
v Fill
v
v Stabilisation
v
v Test
v
v Dump
v
v Pressure unit >
Bar > MPa > kPa
> Pa > PSI >
mbar
v
v Maximum fill
v
v Minimum fill
v
v Filling instruction
v
v Reject unit >
Pa > Pa/s >
Pa(HR) >
Pa(HR)/s >
Cal-Pa > Cal-Pa/s
> cm
3
/mn > cm
3
/s
> cm
3
/h > mm
3
/s
v
v Test reject
v
v Reference reject
v
v Functions > See note
v
v
v
Blockage > Type: blockage > Reset name
v
v Wait A Delete program
v
v Fill
v
v Dump
v
v Pressure unit >
Bar > MPa > kPa
> Pa > PSI >
mbar
v
v Maximum fill
v
v Minimum fill
v
v Filling instruction
v
v Functions > See note
v
v
v
Desensitise > Type: desensitise > Reset name
v
v Wait A Delete program
v
v Fill
v
v Stabilisation
