ATEQ F SERIES User Manual

Chapter 3 – Start-up and settings
UM-23100B-U User manual ATEQ F CLASS Page 27/90
2.3.9. Filling instruction
This function gives the user the option not to have to adjust the test pressure manually
using the regulator. Simply set the test pressure value and the instrument adjusts it
automatically. This function can be used with a mechanical regulator (regulator with an
adjustable knob) or an electronic regulator (no adjustment).
2.3.9. 1) Setting
Simply set the regulator to a pressure which is higher than test pressure. When target
fill pressure is reached, the air supply is automatically cut off and the instrument moves
into stabilisation mode.
2.3.10. Reject unit
Pa, Pa/s, (High Resolution) Pa, (High Resolution) Pa/s, Cal-Pa, Cal-Pa/s, cm
3
/min,
cm
3
/s, cm
3
/h, mm
3
/s.
If a unit of flow is selected, two parameters will be added to the program:
9 the choice of the flow calculation basis, in Pa or Pa/s
9 the volume of the test part (+pipes).
There is a special “calc volume” cycle which enables the volume of a part to be
estimated, and there is a special "Cal learn" cycle to determine a basic unit of flow. (see
chapter 4 paragraph 3.6 "volume calculation" and paragraph 3.7 "manual calibration").
Note: high resolution enables an extra figure to be displayed (i.e. 1/10 Pa)
) Set this parameter using the method described in paragraph 2.3.
2.3.11. Test reject
This function is used to set a limit level below which the part is considered to be bad.
) Set this parameter using the method described in paragraph 2.3.
2.3.12. Reference reject
This function is used to set a limit level below which the reference part is considered to
be bad.
Note: when the reference reject value is zero, the program allows for the absolute value
of the test reject (for example : if the test reject is 10 Pa, and the reference reject value
equal to zero, the program takes the reference reject to be – 10 Pa).
) Set this parameter using the method described in paragraph 2.3.
2.3.13. Functions
The FUNCTION menu gives access to additional parameters which must first be
activated in the CONFIGURATION menu and then the EXTENDED MENU .
If no additional parameters are confirmed in the EXTENDED MENUS , the FUNCTION
menu will be empty when selected.
To activate these parameters, refer to chapter 4 paragraph 2.
