Model X High Speed Sublimation printer
52
Note: Place the air-expansion roller in the bracket so that both ends are placed at the same time.
When removing the inflation roller from the holder, remove both ends at the same time.
(2) Schematic diagram of automatic unwinding
Figure 5-8 Automatic rewinding rollers
Figure 5-9 Overall paper-drawing diagram
Note: When aligning the paper, align the edges of the paper, and make sure that the flat paper is attached to
the suction platform. The printing paper in the whole system should be in the same straight line.
