Atlas Copco C9C Compact - System Overview

Page 10
Unity Bulk Feeder C9C Compact, Issue 1
3 System Overview
1
2
3
4
5
6
7
8
11
12
1 - Hinged lid
2 - Lid key-lock
3 - Top cover
4 - Door
5 - Door handle
6 - Stud lock
7 - Side panel
8 - Lifting handle
9 - Rear panel
10 - Bulk head plate
11 - T-Tube
12 - Main Air inlet Hose
1
2
3
12
11
8
7
9
10
