Page 38
Unity Bulk Feeder C9C Compact, Issue 1
9 Additional Information
9. 1 Technical Data
PERFORMANCE / SPECIFICATION
Rivet feed & setting Ø5mm Rivets
Air consumption 660 L/min. Max.
Power consumption 12W
Operating conditions +5°C to +40°C
Weight (without rivets) 19Kg ± 5%
Humidity
Relative humidity - 15 to 95% (internal), Level RH-2,
no condensation (at 45 °C storage)
SERVICES REQUIRED
Electricity 24V, DC
Air 6 Bar
Clean, dry, class 2 air, ltered to 5microns
Temperature range -5°C to +40°C
Non-lubricated
NOISE
@ 1m (Lid Closed) 78.7dB
9. 2 Disposal
This equipment contains electrical components. Dispose of this equipment responsibly and in
accordance with local environmental requirements and legislation.
Disposal of the equipment is the responsibility of the end-user.
For reference, use the Environmental Data Sheet provided.
