Page 26
Unity Bulk Feeder C9C Compact, Issue 1
Feed the T-Tube through the conduit system and split clamp positioned at the very base
of the Compact Bulk Rivet Feeder.
Then feed the T-Tube upward and through the T-Tube strain relief.
Finally, insert the dressed end of the T-Tube into the escapement tube aperture. On fully
inserting tighten the T-Tube securing fastener.
NOTE
It is advised to give the tube a rm tug to ensure correct locking
engagement of the fastener.
As part of the PM schedule, inspect T-Tube for installation or in service damage.
If damage has been suspected or found, e.g. crushing, kinking, stretching, reduced bend radii etc,
check the T-Tube; if stress marking in plastic are found replace the T-Tube.
