Table 4-14. Atmel-ICE UPDI Pin Mapping
Atmel-ICE AVR port pin Target pins Mini-squid pin Atmel STK600 UPDI pinout
Pin 1 (TCK) 1
Pin 2 (GND) GND 2 6
Pin 3 (TDO) UPDI_DATA 3 1
Pin 4 (VTG) VTG 4 2
Pin 5 (TMS) 5
Pin 6 (nSRST) [/RESET sense] 6 5
Pin 7 (Not connected) 7
Pin 8 (nTRST) 8
Pin 9 (TDI) 9
Pin 10 (GND) 0
4.4.9. TPI Physical Interface
TPI is a programming-only interface for some AVR ATtiny devices. It is not a debugging interface, and
these devices do not have OCD capability. When designing an application PCB which includes an AVR
with the TPI interface, the pinout shown in the figure below should be used.
Figure 4-13. TPI Header Pinout
TPIDATA
TPICLK
/RESET
VCC
GND
1 2
TPI
(NC)
4.4.10. Connecting to a TPI Target
The recommended pinout for the 6-pin TPI connector is shown in Figure 4-13.
Connection to a 6-pin 100-mil TPI header
Use the 6-pin 100-mil tap on the flat cable (included in some kits) to connect to a standard 100-mil TPI
header.
Connection to a 6-pin 50-mil TPI header
Use the adapter board (included in some kits) to connect to a standard 50-mil TPI header.
Connection to a custom 100-mil header
The 10-pin mini-squid cable should be used to connect between the Atmel-ICE AVR connector port and
the target board. Six connections are required, as described in the table below.
Table 4-15. Atmel-ICE TPI Pin Mapping
Atmel-ICE AVR port pins Target pins Mini-squid pin TPI pinout
Pin 1 (TCK) CLOCK 1 3
Pin 2 (GND) GND 2 6
Pin 3 (TDO) DATA 3 1
