156
ATtiny26(L)
1477G–AVR–03/05
Figure 120. Bandgap Voltage vs. V
CC
Figure 121. Analog Comparator Offset Voltage vs. Common Mode Voltage (V
CC
= 5.0V)
BANDGAP vs. V
CC
1.216
1.218
1.22
1.222
1.224
1.226
1.228
1.23
1.232
1.234
1.236
2.5 3 3.5 4 4.5 5 5.5
Vcc (V)
Bandgap Voltage (V)
85°
C
25°
C
-40°
C
ANALOG COMPARATOR OFFSET VOLTAGE vs. COMMON MODE VOLTAGE
Vcc = 5V
0
0.001
0.002
0.003
0.004
0.005
0.006
0.007
0.008
0.009
01234
Common Mode Voltage (V)
Comparator Offset Voltage (V)
85°C
25°C
-40°C
