AudioArts Engineering D-16 - Phone Connection Pinout Details

page 4 – 5
D-16 / Feb 2003
PHONE SECTION
Phone Connection
s
and
Mix-Minus Outputs
DB Connector Pinouts
PHONE IN/OU
T
(DB-25)
CALL 1 IN SH
CALL 1 IN HI
CALL 2 IN LO
CALL 1 OUT SH
CALL 1 OUT HI
CALL 2 OUT LO
AUDIO GROUND
N/C
N/C
MXM 1 OUT SH
MXM 1 OUT HI
MXM 2 OUT LO
AUDIO GROUND
CALL 1 IN LO
CALL 2 IN SH
CALL 2 IN HI
CALL 1 OUT LO
CALL 2 OUT SH
CALL 2 OUT HI
N/C
AUDIO GROUND
N/C
MXM 1 OUT LO
MXM 2 OUT SH
MXM 2 OUT HI
5
4
3
2
1
17
16
15
14
8
7
6
20
19
18
10
9
23
22
21
13
12
11
25
24
