Administrator's Manual 6. Configuring Phone Settings
Version 3.4.3 129 400HD Series IP Phones
Parameter Name Description
system/ldap/call_lookup
Performs an LDAP search during call (search the
display name for a number).
system/ldap/country_code
Defines the country code prefix added for number
search.
system/ldap/area_code
Defines the area code prefix added for number
search.
system/ldap/minimal_name_search_length
Starts to perform an LDAP search after x
characters are input.
system/ldap/send_queries_while_typing
Sends an LDAP search each time the user
presses a key (all keys with both number and
letters).
6.1.1.2 Loading a Text-based Corporate Directory File
The Configuration file can include a link to a user-defined Corporate Directory file, using the
'provisioning/corporate_directory_uri' parameter. This allows you to upload a corporate
directory to the phone.
Three types of corporate directory files are supported: txt, cfg, and xml
The corporate directory file includes a list of contacts and their phone numbers.
The syntax of the corporate directory file must be as follows:
<full name>,<office>,<home>,<mobile>
For example:
John Smith,1234,98765432,574685746
If not all phone numbers are required, the relevant field must be left empty. For example, in
the directory entry below, the home and user-defined numbers are absent:
John Smith,1234,,574685746
To configure the Corporate Directory:
• Use the table as reference.
Table 6-2: Provisioning Parameters
Parameter Description
provisioning/corporate_directory_uri
The URI for retrieving the corporate directory. The
corporate directory must be included in a separate file to
be loaded to the phone during provisioning.
For example:
provisioning/corporate_directory_uri=corporate_dir.txt
Note:
The corporate directory file is loaded after boot up and
after that, periodically.
If the corporate directory file is new, the phone updates
the information and does not reboot.
