400HD Series IP Phones
Administrator's Manual 56 Document #: LTRT-11973
4.4 Configuring VLAN Settings
Network administrators can configure VLAN settings.
To configure the phone's VLAN settings:
• Use the table as reference.
Table 4-8: VLAN Settings
Parameter Description
network/lan/vlan/mode
Determines how VLAN is assigned to your phone, i.e.,
manually or automatically, and if automatically,
according to which protocol.
Disable Disable
Manual Configuration of VLAN Manual - If
selected, the screen extends to also display 'VLAN
ID' and 'VLAN Priority' (see these settings below)
for static configuration of VLAN ID and priority. See
Section 4.4.1 below for a detailed explanation.
Automatic Configuration of VLAN (CDP) CDP -
VLAN discovery mechanism based on Cisco
Discovery Protocol (CDP). See Section 4.4.1 below
for a detailed explanation.
Automatic Configuration of VLAN (LLDP) LLDP -
VLAN discovery mechanism based on LLDP. See
Section 4.4.1 below for a detailed explanation.
Automatic Configuration of VLAN (CDP+LLDP)
CDP_LLDP (default) - VLAN discovery mechanism
based on LLDP and CDP. LLDP is higher priority.
See below for a detailed explanation.
network/lan/vlan/period
The time period, in seconds, between discovery
messages when configured to CDP, LLDP or
CDP+LLDP. The default value is 30.
network/lan/vlan/id
The VLAN ID. The valid range is 0 to 4094. The
default is 0.
network/lan/vlan/priority
The priority of traffic pertaining to this VLAN. The valid
range is 0 to 7 (where 7 is the highest priority). The
default is 0.
network/lan/vlan/pc_port_tagging/enable Default = Disable 0. Change to Enable (1) for the
traffic from the PC to the network to be VLAN-tagged.
4.4.1 Configuring Manual or Automatic VLAN Assignment
Network administrators can configure the VLAN to be assigned manually or automatically to
the phone. This section shows when to configure what, and why.
4.4.1.1 Configuring Manual VLAN Assignment to the Phone
Configure manual assignment of the VLAN in order to set up two separate VLANs in your
enterprise, one for voice (your phone) and the other for data (your pc). Security
considerations may require this. If you configure manual assignment, the switch in your
enterprise will assign the VLAN to your phone. See Sections 4.2.1.1 and 4.2.1.2 for details.
