400HD Series IP Phones
Administrator's Manual 98 Document #: LTRT-11973
5.7 Configuring Extension Lines
Before you can make a call, you must configure an extension line (SIP account) on the
phone.
To configure an extension line (SIP account):
• Use the table as reference. %d refers to the line number.
Table 5-31: Line Parameters
Parameter Description
voip/line/0-5/enabled
Activates or deactivates the line.
0 = Disabled (this is the default for the second line and
higher in the configuration file)
1 = Enabled (this is the default for the first line
voip/line/0/ in the configuration file).
voip/line/0-5/id
Lines VoIP user's ID for identification to initiate and accept
calls. The user's ID can be up to 30 characters.
voip/line/0-5/description
Arbitrary name to intuitively identify the line and that is
displayed to remote parties as your caller ID.
voip/line/0-5/auth_name
User name provided to you from the VoIP service provider.
This is used when sending a response to Unauthorized or
Proxy Authentication Requested (401/407).
The authentication name can be up to 35 characters.
voip/line/0-5/auth_password
Password provided to you from the VoIP Service Provider.
This is used when sending a response to Unauthorized or
Proxy Authentication Requested (401/407).
The authentication password can be up to 35 characters.
voip/line/0-5/extension_display
Applies to all phone models but on the 405HD phone the
parameter is voip/line/0-1/extension_display.
Set the string that will be displayed in the phone screen for
local extension. If not set, the local extension displayed will
be the user ID (self-number).
voip/line/0-5/line_mode
Applies to all phone models.
Determines the line mode: PRIVATE (default) or SHARED.
SHARED allows enterprise employees to share an
extension number and manage a call as a group. When an
employee places a call on a SHARED line on hold, the call
can be resumed from any other employee sharing the line.
Note: You can activate DnD per phone line (see Section 5.8.7).
