AudioCodes Mediant 800 Installation Manual

Installation Manual 5. Recovering CCE Image from USB
Version 2.0.5 53 Mediant 800 CCE & Mediant Server CCE
Figure 5-7: Mediant 800 Boot Override
5. Press Enter; the Mediant 800 OSN server restarts.
Warning: Failure to set the First Boot device and Boot Override correctly can result in
the server performing an endless loop, constantly rebooting from the USB (partitioning,
formatting, and installing Windows each time).

AudioCodes Mediant 800 Specifications

General

Protocols	SIP, H.323
Digital Interfaces	1/2 E1/T1 PRI
Management	Web, CLI, SNMP
Mounting	19-inch rack
Codecs	G.711, G.729, G.722, G.723.1
Power Supply	100-240V AC
Operating Temperature	0 to 40°C
Storage Temperature	-25 to 70°C
Humidity	10% to 90% non-condensing
