○ Paper Binding
• Paper binding should be in both ends, it is not allow paper binding only in one end.
• Paper binding should be in the paper side and the surface should be even.
• Please operate double-ply paper binding along the paper feeding direction.
• Make sure paper binding part is fixed tightly and is not warp.
• Please press it down tightly after paper binding to avoid warping.
Note: Use the paper which is not accordance with the paper binding requirement and the
specification shown below, paper feeding precision may be affected and the printing
performance can not be guaranteed.
Line pulp
1 ~ 2 mm
First
page
Third
page
Second
page
Forth
page
Fifth
page
6.35 Loading direction
Unit: mm
6.35
Fixed tightly
Not fixed tightly
25.4
Transverse perforation
Above 2
Paper binding space is
over 50.8mm (2inches)
3~4
About 1
Press down to
avoid warping
If bind the four
places together
50.8 Space
The size and position of paper
binding (single)
Expanding figure of
the binding part
