AUMA ACV 01.2 User Manual

Default values:
Detect. time dt (for potentiometer/EWG/RWG within actuator) = 00:05.0 min:s ( 5
seconds)
Detect. time dt (MWG) (for MWG within actuator) = 00:00.5 min:s (0.5 seconds)
Setting ranges:
Detect. time dt = 00:01.0 ... 30:00.0 min:s (minutes:seconds)
Detect. time dt (MWG) = 00:00.1 ... 00:02.0 min:s (minutes:seconds)
10.6.3. Travel difference dx
Required user level: Specialist (4) or higher.
Customer settings M0041
Motion detector M0676
Travel diff. dx M0678
Travel diff. dx (MWG) M0679
Default values:
Travel diff. dx (for potentiometer/EWG/RWG within actuator) = 1.0 %
Travel diff. dx (MWG) (for MWG within actuator) = 3 (increments)
Setting ranges:
Travel diff. dx = 1.0 ... 10.0 %
Travel diff. dx (MWG) = 2 ... 20 (increments)
10.6.4. Delay time
Delay time of the signal: Handwheel oper.
Required user level: Specialist (4) or higher.
Customer settings M0041
Motion detector M0676
Delay time M0764
Default value: 6.000 s (seconds)
Setting range: 0.001 ... 65.535 s
10.7. Monitoring of electronics power supply
Actuator controls monitor the following voltages and signal a warning (refer to <Fault
signals and warnings> chapter):
●
Auxiliary voltage 24 V DC, e.g for supplying the control inputs
●
Voltage 24 V AC for controlling the reversing contactors, for thermoswitches
and heater within the actuator and for generating the 115 V AC auxiliary voltage
for the customer (option)
●
Internal 24 V DC power supply of the electronics components (within the actu-
ator controls and in the actuator)
●
External 24 V DC supply of the electronics (option)
Activate monitoring of auxiliary voltage 24 V DC
Required user level: Specialist (4).
Device configuration M0053
Monitoring function M0645
Monitor 24 V DC cust. M0650
Default value: Function not active
Setting values:
Function not active
Monitoring is deactivated.
111
Actuator controls
ACV 01.2/ACVExC 01.2 Profibus DP Monitoring functions
