14.9. Diagnostic Process controller
Required user level: Specialist (4) or higher.
Diagnostics M0022
Process controller M0883
Menu M0883 is only visible if function Process controller M0741 is activated.
The following states can be checked via diagnostic:
SignificationMenu IDParameters
M0884Process setpoint
M0885Actual process value
M0886Op. com. PID contr.
14.10. Profibus interface: diagnostics
This diagnostics provides information on the current status of the Profibus
sub-assemblies.
Required access level: Specialist (4) or higher.
Diagnostics M0022
Profibus DP1 M0240
Profibus DP2 M0549
Details Profibus M0602
For a detailed description of the indications included these menus refer to Manual
(Device integration fieldbus) Profibus DP.
14.11. Diagnostic FO cable
Required user level: Observer (1) or higher.
Diagnostics M0022
FO cables M0638
The following states can be checked via diagnostic:
SignificationMenu IDParameters
M0639FOC level channel 1
M0640DIN 4 configuration
M0762FOC RS-485 error
M0641FO cable baud rate
M0711FOC FPGA version
14.12. Simulation (inspection and test function)
The service personnel or the commissioning engineer can use this simulation function
to simulate the operation and failure behaviour of the actuator or the actuator controls
to check the interface to the DCS and the correct behaviour of the DCS.
14.12.1. Actuator signals
By simulating the actuator signals, the signal behaviour of the actuator controls to
the DCS can be tested, for example, without having to connect the actuator.
Required user level: Specialist (4) or higher.
Diagnostics M0022
Simulation M0023
Actuator signals M0024
Simulation values:
End position OPEN
End position OPEN reached.
End position CLOSED
End position CLOSED reached.
132
Actuator controls
Diagnostics ACV 01.2/ACVExC 01.2 Profibus DP
