AUMA ACV 01.2 User Manual

Units M1205
Signal outputs (AOUT) M1221
Sig. outp. activ. (AOUT) M1222
Default value: Function not active
Setting values:
Function not active
<Signal output units (AOUT)> function deactivated.
Function active
<Signal output units (AOUT)> function activated.
Set max. value, scaling and unit
Required user level: Specialist (4) or higher.
Display M0009
Units M1205
Signal outputs (AOUT) M1221
Max. value at 100.0 % M1223
Scaling M1224
Unit M1225
Default values:
Max. value at 100.0 % = 1000
Scaling = 1
Unit = mA
Setting ranges/values:
Max. value at 100.0 % = 1 – 1000
Scaling = 0.001 – 1000 (multiplier factor for unit)
Unit = mA; °C; bar; m³/h; m³/min; m; cm; mm; °
7.6. Contrast
The contrast can be used to adapt the display backlight (light or dark background).
Display M0009
Contrast M0230
48
Actuator controls
Basic settings for commissioning ACV 01.2/ACVExC 01.2 Profibus DP
