On
Monitoring is activated. Should the auxiliary voltage 24 V DC for supplying the control
inputs fail, a warning will be issued.
Activate monitoring of external supply 24 V DC
Required user level: Specialist (4).
Device configuration M0053
Monitoring function M0645
Monitor 24 V DC ext. M0649
Default value: Function not active
Setting values:
Function not active
Monitoring is deactivated.
On
Monitoring is activated. Should the external supply 24 V DC fail, a warning will be
issued.
10.8. Temperature monitoring
Characteristics
If the respective sensors are installed in the devices, the actuator controls monitor
different temperatures.
If certain temperature limits are exceeded or fallen short of, the controls either send
a warning or a fault signal.
Conditions:
●
For temperature within the control unit of the actuator: MWG (magnetic limit
and torque transmitter)
●
For motor temperature: additionally temperature sensor (PT 100) in the motor
●
For gear housing temperature: additionally temperature sensor (PT 100) in the
gearing
Information
Current device temperatures can also be displayed. Refer to <Display device tem-
peratures>.
10.9. Heater system/heater monitoring
The heater system within the actuator controls housing and the heater on the control
unit (within the switch compartment of the actuator) can be monitored. If the monitoring
is activated the following warning will be generated if the heater system or the heater
(circuit = interrupted) fails:
●
In the display of the local controls, status indication S0005 Warnings
-
Details: Internal warning Wrn heater
●
Via fieldbus: Wrn heater
For further information on the heater system and the heater refer to separate <Heater
system and heater> chapter.
Activate heater system monitoring
Heater system monitoring monitors all connected heaters for failure.
Required user level: Specialist (4).
Device configuration M0053
Monitoring function M00645
Monitor heat. system M0647
Default value: Function not active
Setting values:
Function not active
Heater monitoring is deactivated.
Function active
Heater monitoring is activated.
112
Actuator controls
Monitoring functions ACV 01.2/ACVExC 01.2 Profibus DP
