AUMA ACV 01.2 User Manual

Speed internal 4 M1933
Default values: 45 rpm
Setting range: The adjustable speed range is indicated on the actuator name plate.
8.1.3. Speed range for analogue input: set
This setting is only effective if one of the speed sources is either set to Analogue
input or Fieldbus.
Customer settings M0041
Speed functions M1699
Speed rem. min. M1936
Speed rem. max M1937
Default values:
Speed rem. min. = 6 rpm (≙ 0/4 mA)
Speed rem. max = 60 rpm (≙ 20 mA)
Setting values:
Speed rem. min. = 6 ... 240 rpm (revolutions/minute)
Speed rem. max = 6 ... 240 rpm (revolutions/minute)
The adjustable speed range is indicated on the actuator name plate.
8.1.4. Time for speed increase and time for speed reduction at pivot points
The transition time from a low to a high speed can be set.This applies e.g. to speed
transition within pivot point range. Refer to <Speed profile>.
Figure 33: Example of time for speed increase
n Output speed
P Pivot point
t Operating time (travel)
t↗
Time for speed increase
Set time for speed increase
Customer settings M0041
Speed functions M1699
Time speed incr. M1769
Default values:
Time speed incr. = 0.2 s (seconds) from lower to higher speed
Setting ranges:
Time speed incr. = 0.1 – 10.0 (seconds)
51
Actuator controls
ACV 01.2/ACVExC 01.2 Profibus DP Application functions
