Required user level: Specialist (4) or higher.
Customer settings M0041
EMCY behaviour M0198
Bypass speed profile M0596
Default value: Off
Setting values:
Off
No by-pass of torque profile. In EMERGENCY operation, the actuator operates into
the EMERGENCY position following the pre-set speed profile.
On
The speed profile is by-passed. In EMERGENCY operation, the actuator operates
into the EMERGENCY position at EMERGENCY speed (Speed EMCY OPEN
parameters M1934 or Speed EMCY CLOSE M2041). Refer to <EMERGENCY
speed> chapter.
9.3.15. Delay time for EMERGENCY operation
An EMERGENCY operation is only performed once the delay time has expired.
Consequently, a short-term signal failure will not have an impact on the process and
will not immediately initiate an EMERGENCY operation.
Required user level: AUMA (6) or higher.
Customer settings M0041
EMCY behaviour M0198
Delay time M0804
Default value: 00:01.00 min : s
Setting range: 00:00.0 ... 30:00.0 min : s
9.4. Enable local controls
Application
●
Protection against unauthorised operation via local controls
●
Protection against unauthorised parameter setting via local controls
Properties
The selector switch functions LOCAL and/or OFF may be enabled or disabled.
Enable/disable local controls via fieldbus commands
For control via fieldbus interface, the command for enabling the local controls is done
via fieldbus command Fieldb. enable LOCAL.
Switching behaviour:
●
Fieldb. enable LOCAL = 1 = enable:
Operation via local controls enabled
●
Fieldb. enable LOCAL = 0 = disabled:
Operation via local controls disabled
Information
In the event of loss of fieldbus communication, the local controls will be disabled
since no enable signal is present.
If operation commands are not transmitted via fieldbus commands, but via <Additional
inputs> or an additional <Parallel interface>, a digital input has to be available and
configured to enable/disable the local controls.
Configuration of digital input
Required user level: Specialist (4).
Device configuration M0053
I/O interface M0139
Digital inputs M0116
Example
Use input DIN 5 for signal Enable Local:
Parameters: Signal DIN 5 M0122
Setting value: Enable Local (wiring diagram designation: Enable LOCAL)
92
Actuator controls
Failure functions ACV 01.2/ACVExC 01.2 Profibus DP
