X to Y mA
The signal range (X-Y) of the analogue output can be freely configured using two
parameters.
5.4.3. Adjustment of analogue output 1
Initial values and end values of the signal range can be corrected by ± 10 % of the
maximum value range (20 mA)
Example: Parameter Signal range AOUT1 = 4 - 20 mA
The initial value (4 mA) can be adapted within a range of 2 mA to 6 mA.
The end value (20 mA) can be adapted within a range of 18 mA to 22 mA.
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Analogue outputs M0335
Adjustment AOUT 1 M0544
0/4 mA (initial value) M0140
20 mA (final value) M0210
Default value: 0
Setting ranges: –10.0 ... 10.0 % (in %)
5.4.4. Assignment of analogue output 2
Required user level: Specialist (4).
Device configuration M0053
I/O interface M0139
Analogue outputs M0335
Signal AOUT 2 M0132
Default value: Torque
Setting values:
Description see <Assignment of analogue output 1>.
5.4.5. Signal range of analogue output 2
Required user level: Specialist (4) or higher.
Device configuration M0053
I/O interface M0139
Analogue outputs M0335
Signal range AOUT2 M0130
Default value: 0 - 20 mA
Setting values:
0 - 20 mA
Analogue output 2 generates a 0 – 20 mA signal.
4 - 20 mA
Analogue output 2 generates a 4 – 20 mA signal.
20 - 0 mA
Analogue output 2 generates a 20 – 0 mA signal.
20 - 4 mA
Analogue output 2 generates a 20 – 4 mA signal.
X to Y mA
The signal range (X-Y) of the analogue output can be freely configured using two
parameters.
5.4.6. Adjustment of analogue output 2
Initial values and end values of the signal range can be corrected by ± 10 % of the
maximum value range (20 mA)
Example: Parameter Signal range AOUT1 = 4 - 20 mA
The initial value (4 mA) can be adapted within a range of 2 mA to 6 mA.
The end value (20 mA) can be adapted within a range of 18 mA to 22 mA.
30
Actuator controls
Signals (output signals) ACV 01.2/ACVExC 01.2 Profibus DP
