DescriptionSignal
Collective signal 19:
This signal can be configured (parameter Fault (Cfg) M0880) and comprises a combination of the following
signals:
Configuration error
Config. error REMOTE
Internal error
Torque fault CLOSE
Torque fault OPEN
Phase fault
Incorrect phase seq
Mains quality
Thermal fault
Fault no reaction
Wrn input AIN 1
Wrn input AIN 2
Rectifier fault
DMF fault OPEN
DMF fault CLOSE
Fault (configurable)
Collective signal 20:
This signal can be configured (parameter Warnings (Cfg) M0881) and comprises a combination of the
following signals:
Config. warning
Internal warning
24 V DC external
Wrn op.mode run time
Wrn op.mode starts
Failure behav. active
Wrn input AIN 1
Wrn input AIN 2
Wrn setpoint position
Op. time warning
Wrn controls temp.
Time not set
RTC voltage
PVST fault
PVST abort
Wrn no reaction
Wrn FOC
Wrn FO cable budget
Wrn FOC connection
Torque wrn OPEN
Torque wrn CLOSE
PVST required
Maintenance required
AUMA warning 2
Warnings (Cgg)
Collective signal 21:
This signal can be configured (parameter Not ready REMOTE (Cfg) M0882) and comprises a combination
of the following signals:
Wrong oper. cmd
Sel. sw. not REMOTE
Service active
EMCY stop active
EMCY behav. active
I/O interface
Handwheel active
FailState fieldbus
Local STOP
Interlock
Interlock by-pass
PVST active
Not ready REM (Cfg)
Actuator is in pause time of stepping mode.
Operation pause active
152
Actuator controls
Appendix ACV 01.2/ACVExC 01.2 Profibus DP
