Maintenance Manual
E4.08.04
Issue date: 14-Dec-2015
Page: 24-21
Fig. 24 - 30..Alternator with removed plastic cover
Remove Brush Holder Assembly E4A-91-410-000 carefully.
Fig. 24 - 31 Alternator with removed plastic cover
R1
R3
Brush Holder Assembly E4A-91-410-000
T2
R2
Remove Direction of Brush Holder Assembly
