Austro Engine AE300 Service Manual

Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 71-6
Revision no: 25
71-50-10 Engine Wiring Harness E4A-90-000-000
Inspect the engine harness for chafing, damage or missing clamps.
In case of signs of wear or damage replace the engine wiring harness.
Fig. 71 - 1
Pay attention for correct interlocking and snapping of the plug and socket connections
(e.g. ECU connector or Injector connector)
PCV
INJ 3
INJ 4
CAS 1
FTS
FPS
FMU
INJ 2
INJ 1
GP 4
GP 3
GP 2
GP 1
GPC
CTS_GPC
GBTS
CRS 2
MOK
GEN
OPS
CRS 1
GOV
CTS
BPS2
BPS1
IAT 2
IAT 1
RPS
BPA
CAS 2
Connection EECU
Connection Cockpit
