Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 71-28
Revision no: 25
71-50-130 Sensor – Check
The sensors have to be inspected for loosened, chafed or damaged connectors according to the
attached list and schematic.
Damaged sensors have to be replaced.
71-50-140 Description Plug Connector Wiring Harness
Wiring
diagram
Description long version
German description
FPS
Fuel Pressure Sensor
Kraftstoffdrucksensor
RPS
Rail Pressure Sensor
Raildrucksensor
MOK
Oil Combinant Sensor
Temperature
Kombinierter Ölsensor Temperatur
BPS1
Boost Pressure Sensor 1
Ladedrucksensor
BPS2
Boost Pressure Sensor 2
Ladedrucksensor
OPS
Oil Pressure Sensor
Öldrucksensor
IAT 1
Intake Air Temperature 1
Ladelufttemperatursensor
IAT 2
Intake Air Temperature 2
Ladelufttemperatursensor
CTS
Coolant Temperature Sensor
Kühlwassertemperatur
GBTS
Gearbox Temperatur Sensor
Getriebetemperatursensor
CTS_GPC
GPC Coolant Temperature
Kühlwassertemperatursensor GPC
FTS
Fuel Temperature Sensor
Kraftstofftemperatursensor
CAS 1
Camshaft Sensor 1
Nockenwellensensor
X)
CAS 2
Camshaft Sensor 2
Nockenwellensensor
ECU A
ECU A
ECU A Stecker
ECU PWR
ECU Power
ECU Power Stecker
ECU B
ECU B
ECU B Stecker
GEN
Alternator Plug
Alternator Stecker
GPC
GPC Connector
GPC Stecker
CRS 1
Crankshaft Sensor 1
Kurbelwellensensor 1
CRS 2
Crankshaft Sensor 2
Kurbelwellensensor 2
GOV
Governor Actuator
Governor
GPC
Glow Plug Control
GPC Glow Plug Control
GP 1
Glow Plug 1
Glühkerze 1
GP 2
Glow Plug 2
Glühkerze 2
GP 3
Glow Plug 3
Glühkerze 3
GP 4
Glow Plug 4
Glühkerze 4
W11 / 1
Ground Connection GPC
Masse Verbindung für GPC
W11 / 2
Ground Connection Governor
Masse Verbindung für Governor
X1/1
CPC 1 A/C Interface 1
CPC 1
X1/2
CPC 2 A/C Interface 2
CPC 2
BPA
Boost Pressure Actuator
EPW
PCV
Pressure Control Valve
Druckregelventil Rail
INJ 1
Fuel Injector 1
Injektor
X)
INJ 2
Fuel Injector 2
Injektor
X)
INJ 3
Fuel Injector 3
Injektor
X)
INJ 4
Fuel Injector 4
Injektor
X)
FMU
Fuel Metering Unit
Zumesseinheit
X) This Sensors can only be checked all 300h if the Injector cover is removed.
