79-00-103 Removal of the Lubricant Line Sealing Ring
1. Remove the lubricant line [1] – refer to Chapter 79-00-101.
2. Remove the sealing ring [3] at the banjo bolt [4].
3. Remove the O-ring. [2].
79-00-104 Installation Lubricant Line Sealing Ring
1. Install the new O-ring and lubricate it with acid free lubrication.
2. Install the new sealing rings [3].
3. Install the lubricant line [1] – refer to Chapter 79-00-102.
4. Perform an engine ground run according to Chapter 71-00-03.
5. After the ground run inspect oil system for leakage.
6. The lubricant line banjo bolt has to be torqued again after cooling down the engine.
Fig. 79 - 15
