79-00-60 Oil-Filter Housing
79-00-61 Removal of the Oil-Filter Housing
1. Remove the oil filter housing drain line – refer to Chapter 79-00-11.
2. Remove the fitting [9] from the oil filter housing drain line.
3. Remove the oil filter – refer to Chapter 79-00-71.
4. Remove the (OPS) Oil pressure sensor [3] – refer to Chapter 79-00-131
5. Remove the screws [5], [6] and the screw [7] with the clamp [8] of the wiring
harness.
6. Remove the oil filter housing.
79-00-62 Installation of the Oil-Filter Housing
1. Use new O-rings [4], lubricate it with acid free lubrication.
2. Install the oil filter housing carefully.
3. Screw it down with the screws [5], [6] and [7) and torque them with 9 Nm.
(do not forget the claps from the wiring harness)
4. Install the (OPS) Oil pressure sensor [3] – refer to Chapter 79-00 132
5. Install the oil filter – refer to Chapter 79-00-72.
6. Install the fitting [9] from the draining line with a new sealing ring and torque with
18 Nm.
7. Install the oil filter housing drain line – refer to Chapter 79-00-12.
8. Clean the working area.
9. Perform an engine ground run according to Chapter 71-00-03.
10. After the ground run inspect oil system for leakage.
For picture see Chapter 79-00-72.
