Austro Engine AE300 Service Manual

Maintenance Manual
E4.08.04
Issue date: 27-Jan-2011
Page: 79-15
Revision no: 5
79-00-113 Removal of the Oil Return Line Gasket
1. Remove the oil return line – refer to Chapter 79-00-111.
2. Remove the O-ring [1]
3. Remove the gasket [2]
4. Remove the sealing rings [3].
79-00-114 Installation of the Oil Return Line Gasket
1. Install the new O-ring [1] and lubricate with acid free lubrication.
2. Install the new sealing rings [3].
3. Install the new gasket [2].
4. Install the oil return line – refer to Chapter 79-00-112.
Fig. 79 - 17
1
3
2
