Austro Engine AE300 - Removal of the Front Cylinder Head Cover; Removal of the Chain Tensioner

Maintenance Manual
E4.08.04
Issue date: 14-Dec-2015
Page: 85-51
Revision no: 26
85-30-46 Removal of the front cylinder head cover
1. Remove the screws [02].
2. Remove the front cylinder head cover [01] and the O-ring [03].
Fig. 85 - 67
85-30-47 Removal of the chain tensioner
1. Remove the chain tensioner with the sealing ring [01] from the cylinder head.
Fig. 85 - 68
5x
02
01
03
01
