79-00-130 Oil Pressure Sensor
79-00-131 Removal of the Oil Pressure Sensor
1. Disconnect the electrical connector (OPS) [1].
2. Remove the sensor [2].
Use a clean cloth during removal of the oil-level-sensor. Some oil may be discharged by
the oil-level-sensor.
79-00-132 Installation of the Oil Pressure Sensor
1. Put on a new sealing ring.
2. Screw down the new oil pressure sensor [2] with 20 Nm using Loctite 542.
When using Loctite, make sure, that the thread is free of grease and apply only a thin
film of Loctite.
3. Connect the electrical connector (OPS) [1].
4. Clean the working area.
5. Perform an engine ground run according to Chapter 71-00-03.
6. After the ground run inspect oil system for leakage.
Fig. 79 - 19
